Arched Trapezoidal Sheet Roll Forming Machin Efficienty Width 835 / 828 / 840mm

Arched Trapezoidal Sheet Roll Forming Machin Efficienty Width 835 / 828 / 840mm

configurations	manual decoiler, main machine of roll forming, cutting device, output table, electric motor, PLC control system
Material	processing material	Colored Steel plate, Galvanized Board, Aluminum Plate
	thickness	0.3mm-0.8mm
	Efficienty width	835/828/840mm
	Coil width	1000mm
Manual decoiler	The maximum load capacity:5 ton			Expand by band
	The coil inside diameter:450-550mm
	Suitable Coil width:1250mm
Main Forming machine	Forming steps		13steps
	Shaft diameter		70 mm
	Thick of arch frame		16mm
	Frame body		High strength steel pipe weld with color steel sheet cover
	roller material		45# steel
	shaft material		45# steel
	cutter material		Cr12 mold steel with quenched treatment
	Transmission		By 1” chain
	Work speed		20-25m/min
Hydraulic system	Automatic hydraulic cutting after forming, without wasting.
Control Device	PLC control touch screen Program language: English/Chinese(or as required)
Operating mode	Button+touch screen
	Total power	4 kw
	Main body color	Blue and orange(or as required)
	Voltage	380v/50hz/3ph(or as required)

Installation and training:

A. If buyers visit our factory and check the machine, we will teach you how to install and use the machine,
and also trainyour workers/technician face to face.
B. Without visiting, we will send you user manual and video to teach you to install and operate.
C. If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.

After service

A. One year guarantee for whole machine.
B. 24 hours technical support by email or phone call.
C. If there is any problem found of the machine, we will repair it for free in one year.
